Optional inflation with nitrogen or air.
Equipment adopts high-octane BF-220# Carbon molecular sieve and coreaccessories are imported.
By presetting pressure, the equipment can vacuum, fill N2 and test pressureautomatically.
Pressure sensor of high precision made by US Novasensor.
Additional vacuum equipment is unnecessary. Just one button can complete vacuum and nitrogen inflation.
Technical Details :
|
AC110V/220V/50~60Hz |
Power supply |
|
60w |
Power |
|
95~99.5% |
Nitrogen Purity |
|
8~10Bar/116~145Psi |
Compressed Air Input Range |
|
70L |
Nitrogen Storage Tank |
|
66L |
Nitrogen Output |
|
≤87psi/6.0bar |
N2 Output Pressure |
|
+5℃~+70℃ |
Operation Temp |
|
5~110Psi/0.3~8Bar |
Measuring Range |
|
±0.5Psi/0.03Bar |
Accuracy |
|
1420(H)X720(L)X510(W)mm |
Dimension |
|
128kg |
Net weight |
